Post-incineration Framework
CLEANER PLACES
STRONGER COMMUNITIES
A BRIGHTER TOMORROW
Built on Appropriate Technology
No Smoke. No Odor. Just Flow.
The machine is simple. The Behavior is the Technology. Watch it Run. →
Small unit. Big system. One unit is local. Multiple units become infrastructure.
Scale by number. Distribute by need. Operate Locally. Monitor Centrally.
Build it Where You need it.
A METHOD TO SHARE. NOT A MACHINE TO SELL.
AZADrg.net exists to share, support, and reproduce this method on a non-commercial basis.
FEATURES
One Chamber
-
No Smoke. No Odor from ignition.
-
Continuous feed of waste into the upper
-
Wet waste disposal possible
No Lid Needed
-
Demonstrated compliance in prior emission testing without additional exhaust-treatment equipment.
Locally Built
-
Built Locally. Operated Locally.
-
Manual operation available
-
Built to Work. Built to Last.
Low Build Cost
-
Indicative local build cost: typically
300–1000 mm: < USD 200 / 100 mm ID
1500 mm and above: project-specific
(Actual costs vary by location
and build specifications)
SCALE
Scalable by Design
-
300~3000mm ID
-
Parallel connection, medium-to-large scale effect
-
Add capacity one unit at a time
Built to Last
-
Refractory brick
construction -
Semi-permanent lifespan
-
Easy to maintain
-
Portable production
available -
On-site repair
Parallel
-
24-hour operation
-
Steam boiler power generation(WtE)
-
Keep the site operating during maintenance
SPCW capacity
-
Indicative SPCW capacity:
~1 ton/day / 1,000 mm ID
(Actual throughput varies by
SPCW type and condition)
WHERE
ISLANDS
Move Less Waste. Treat It Closer.
REMOTE AREAS
Build Where Infrastructure Cannot Reach.
SMALL CITIES & OUTSKIRTS
Distribute Capacity. Avoid Overbuilding.
Treat What Sorting Leaves Behind.
MRF RESIDUALS
Stop Carrying It Back and Forth.
MARINE WASTE
REMOTE HOSPITAL & FACILITIES
Treat Difficult Waste Where It Arises.
Take Treatment to the Waste.
MOBILE OPERATIONS
Bring Capacity Where Land Is Limited.
SHIPS & BARGES
HUMANITARIAN & NGO OPERATIONS
Build Capability, Not Dependency.
EVIDENCE
SGS TEST RESULTS
* Measured during field operation in Thailand.
0.0
Opacity
~16 ppm
NOx
Not Detected
SO₂
~4.4 mg/Nm³
Particulates (TSP)
0.00229 ng-TEQ/Nm³
Dioxins & Furans
These results were obtained without downstream emission-control equipment —
no scrubber or other flue-gas treatment system was used.
EXAMINE THE FULL TEST RESULTS → Quick link
FIELD RECORD
Built. Fired. Observed
VIEW AFC-500 FIELD VIDEOS → Quick Link
Participation
